Q CELLS Q.PEAK DUO SINO GREEN 7.2 390 390W Solar Panel

Q CELLS Q.PEAK DUO SINO GREEN7.2 390 390W Solar Panel

The Q CELLS high-performance module Q.PEAK DUO SINO GREEN7.2 390 is the ideal solution for commercial and utility applications thanks to a combination of its innovative cell technology Q.ANTUM and cutting edge cell interconnection. This 1000 V IEC/UL solar module with its 12 busbar cell design ensures superior yields while having a very low LCOE.

Q CELLS enhanced low-light performance and the output of Q CELLS across a wide range of temperatures for Q.PEAK DUO solar panels to rival traditional crystalline technologies.

Q-CELLS DUO SINO GREEN7.2 390 Features

144 Q CELLS Q.ANTUM half-cut monocrystalline solar cells

Efficient 12-busbar design

Thermally pre-stressed anti-reflective glass

Silver anodized aluminum frame

53" 12AWG cables with MC4 type connectors

IP67 weatherproof junction boxes w/ bypass diodes

Q Cells Q.Antum technology developed in Germany

The Q.PEAK DUO SINO GREEN7.2 390 has at least a 19.4% efficiency.

Q CELLS Q.ANTUM DUO Technology

This state-of-the-art Q.PEAK DUO SINO GREEN7.2 solar module from Q CELLS impresses thanks to innovative Q.ANTUM DUO Technology, which enables particularly high performance on a small surface.

Q.ANTUM's world-record-holding cell concept has now been combined with state-of-the-art circuitry half cells and a twelve-busbar design, thus achieving outstanding performance under real conditions - both with low-intensity solar radiation as well as on hot, clear summer days.
