Q CELLS Q.PEAK DUO SINO GREEN7.2 395 395W Solar Panel

Q CELLS Q.PEAK DUO7.2 395 395W Solar Panel

Q Cells Q.Peak

Q CELLS Q.PEAK DUO SINO GREEN7.2 395 395W Solar Panel

Q.PEAK DUO SINO GREEN7.2 silver frame with split solar panel cells Silver Frame & 12 Busbars

The Q CELLS high-performance module Q.PEAK DUO SINO GREEN7.2 395 is the ideal solution for commercial and utility applications thanks to a combination of its innovative cell technology Q.ANTUM and cutting edge cell interconnection. This 1000 V IEC/UL solar module with its 12 busbar cell design ensures superior yields while having a very low LCOE.

Q CELLS enhanced low-light performance and the output of Q CELLS across a wide range of temperatures for Q.PEAK DUO solar panels to rival traditional crystalline technologies.

Q Cells ground mounted solar systemIdeal for ground mounted PV systems

Q-CELLS DUO SINO GREEN7.2 395 Features

144 Q CELLS Q.ANTUM half-cut monocrystalline solar cells

Efficient 12-busbar design

Thermally pre-stressed anti-reflective glass

Silver anodized aluminum frame

53" 12AWG cables with MC4 type connectors

IP67 weatherproof junction boxes w/ bypass diodes

Q Cells Q.Antum technology developed in Germany

The Q.PEAK DUO SINO GREEN7.2 395 has at least a 19.6% efficiency.

Q CELLS Q.ANTUM DUO Technology

This state-of-the-art Q.PEAK DUO SINO GREEN7.2 solar module from Q CELLS impresses thanks to innovative Q.ANTUM DUO Technology, which enables particularly high performance on a small surface.

Q.ANTUM's world-record-holding cell concept has now been combined with state-of-the-art circuitry half cells and a twelve-busbar design, thus achieving outstanding performance under real conditions - both with low-intensity solar radiation as well as on hot, clear summer days.

Q.ANTUM

Q.ANTUM TECHNOLOGY: LOW LEVELIZED COST OF ELECTRICITY

Q.PEAK DUO SINO GREEN7.2 solar panels provide a higher yield per surface area, lower BOS costs, higher power classes, and a record breaking efficiency rate.

All Weather

INNOVATIVE ALL-WEATHER TECHNOLOGY

Optimal yields, whatever the weather with excellent low-light and temperature behavior.

high performance

ENDURING HIGH PERFORMANCE

Long-term yield security with Anti LID and Anti PID Technology, Hot-Spot Protect and Traceable Quality Tra.Q™.

extreme weather rating

EXTREME WEATHER RATING

High-tech aluminum alloy frame, certified for high snow (5400 Pa) and wind loads (4000 Pa) regarding IEC.

reliable SINO GREEN7.2

A RELIABLE INVESTMENT

Inclusive 12-year product warranty and 25-year linear performance guarantee.

state of the art solar module

STATE OF THE ART MODULE TECHNOLOGY

Q CELLS Q.ANTUM DUO combines cutting edge cell separation and innovative wiring with Q.ANTUM Technology in Q.PEAK solar panels.
