Sino Green-Pitched Tile Roof Mounting System

Project Site:: Sloped roof tile

Tile type:: Most tile roof

Slope of roof:: Up to 60°

Max Building Height:: Up to 20m

Tags:

Detail

Project Site:： Sloped roof tile

Tile type:： Most tile roof

Slope of roof:： Up to 60°

Max Building Height:： Up to 20m

Wind Load:	88m/s
Snow Load:	1.4kn/㎡
Applicable Module:	Frame / frameless, crystalline/ thin film module
Module Orientation:	Landscape or Portrait
Standard:	AS/NZS 1170, MCS, JIS &SGS

Product Features

1. Pitched tile roof mounting structures are widely used for both crystalline and thin film module

2. Easy & quick installation

3. Few components and no more than two kinds of tools in whole system fixation

4. All pitched roof components are made with high quality aluminum & stainless steel

System Overview

Key Components:

Key Components

Key Com Key Components ponents

Key Components DKEY Key Components

Rail in Customized Length

Rail Connectors

Mid Clamps

End Clamps

Roof Hook
