Sino Green-Tin Roof Mounting System

Project Site:: corrugated or trapezoidal sheet metal roof

Slope of roof: Up to 60°

Max Building Height:: Up to 20m

Wind Load:: 88m/s

Tags:

Detail

Project Site:： corrugated or trapezoidal sheet metal roof

Slope of roof： Up to 60°

Max Building Height:： Up to 20m

Wind Load:： 88m/s

Snow Load:	1.4kn/㎡
Applicable Module:	Frame / frameless, crystalline/ thin film module
Module Orientation:	Landscape or Portrait
Standard:	AS/NZS 1170, MCS, JIS &SGS
Material:	Stainless steel 304, Al6005-T5

Product Features

1. Pitched Tin Roof Mounting Structures are widely used for both crystalline and thin film module

2. Easy & quick installation

3. Only 3-4 kinds of components and no more than two kinds of tools in whole system fixation

4. All pitched roof components are made with high quality aluminum & stainless steel

System Overview

Key Components

Rail in Customized Length

Rail Connectors

Mid Clamps

End Clamps

L Foot
